High-Speed Performance Short-Drum Racing Winch
The Carbon Offroad Scout Pro RS Series winches are built for competition and extreme high-line-speed operations. The RS9-S (Short Drum) combines massive motor output with a compact chassis for applications where space is limited but maximum speed is required.
⚠️ PLEASE NOTE: WINCH ONLY CONFIGURATION
This listing is for the winch unit only (with synthetic rope attached). Accessories such as remotes, isolator switches, hooks, external cabling, fairleads, and mounting hardware are not included and must be sourced separately. This is ideal for custom racing rigs or tight bumper extractions requiring a high-performance bare unit.
Overview
The RS9-S utilizes the shortened 2023 Version 3 winch chassis. By utilizing a narrow drum, this winch fits into tight mounting locations where a full-sized winch cannot. Despite its compact footprint, it is powered by a massive 8.0HP motor and a performance-tuned 80:1 gear ratio, delivering blistering line speeds.
The RS9-S comes spooled with 24m (80ft) of 8mm high-density pre-stretched premium UHMWPE synthetic rope, boasting a massive 14,000lb minimum breaking strain. Because of the extended length of the 8.0HP motor, please consult the technical drawings to ensure clearance in your specific winch mount.
Features
-
Compact Short Drum: Designed for tight mounting spaces with a specialized 164mm x 114.3mm bolt pattern.
-
Extreme Line Speed: Tuned with an 80:1 heavy-duty performance gearbox for rapid recovery cycles in racing environments.
-
Class-Leading Power: Driven by a high-output 8.0HP 12V series-wound electric motor.
-
Rugged V3 Chassis: Built on the shortened 2023 Version 3 chassis with IP68 rated water and dust sealing.
-
High-Strength Rope: Includes 24m of premium Spectra™ Fiber Synthetic UHMWPE rope with a HD braced rope thimble.
Contents
1 x Carbon Offroad RS9-S 9000lb Short Drum Winch Unit
1 x Synthetic Winch Rope (8mm x 24m attached to drum)
| Feature |
Specification Metric (Imperial) |
| Rated Line Pull |
4080kg (9000lb) single-line |
| Motor |
8.0HP 12V Series-Wound |
| Gear Ratio |
80:1 Heavy-Duty Performance Gearing |
| Synthetic Rope |
8mm x 24m (5/16" x 80ft) |
| Rope Material |
Spectra™ Fiber Synthetic UHMWPE |
| Sealing |
IP68 Rated (Water & Dust) |
| Drum Dimensions |
63mm x 122mm (2.5" x 4.8") |
| Mounting Bolt Pattern |
164mm x 114.3mm (6.46" x 4.5") |
| Winch Dimensions (L x W x H) |
385mm x 115mm x 120mm (15.16" x 4.53" x 4.7") |
| Winch Weight |
22kg (48.4lb) |
Performance Specs
| Line Pull Metric (Imperial) |
Line Speed Metric (Imperial) |
Motor Current (Amps) |
| 0kg (0lbs) |
24.2m/min (79.4fpm) |
55A |
| 1816kg (4000lbs) |
5.6m/min (18.4fpm) |
180A |
| 3180kg (7000lbs) |
4.2m/min (13.8fpm) |
310A |
| 4090kg (9000lbs) |
2.6m/min (8.5fpm) |
440A |
Rated Line Pull by Layer
| Layer |
Rated Line Pull Metric (Imperial) |
| 1 |
4090kg (9000lbs) |
| 2 |
3524kg (7760lbs) |
| 3 |
3040kg (6690lbs) |
| 4 |
2615kg (5760lbs) |
