Aluminium Rear Bar — Isuzu D-Max (2017–2019)
Spotlights NOT Included — Available Separately
Installation Manual
Weight: 45 kg
Want the protection of the RIVAL Aluminium Rear Bar for your Isuzu D-Max without the integrated spotlights? This No Lights version delivers the same heavy-duty, high-strength aluminium rear bumper replacement — ready for you to fit your own preferred lighting setup or keep it clean and streamlined. It’s the perfect choice for D-Max owners who already have aftermarket lighting or simply want a clean rear-end look while still getting genuine off-road-grade protection for outback touring, beach driving and daily worksite duties.
- ✓ High-Strength Aluminium Construction — Lightweight yet tough rear-end protection
- ✓ Spotlights NOT Included — RIVAL Spotlights and RIVAL by Osram LED Lights available separately
- ✓ Tow Bar Compatible — Works with factory and aftermarket tow hitches
- ✓ Towing Rating: 3,500 kg
- ✓ Corrosion-Resistant — Powder-coated matte black finish
- ✓ Sensor Compatible — Works with factory rear parking sensors
- ✓ Integrated WLL 5,000 kg Recovery Points
- ✓ Direct Bolt-On Design — Full OE rear bumper replacement
Key Features
-
Material: 4mm high-strength aluminium alloy (5284 H111 grade)
-
Weight: 45 kg — significantly lighter than steel alternatives
-
Finish: Textured matte black powder coat
-
Recovery Points: Integrated WLL 5,000 kg rated recovery points
-
Towing Rating: 3,500 kg
-
Sensor Compatibility: Yes — compatible with factory rear parking sensors
-
Lighting: Not included — light-ready mounting provisions; RIVAL Spotlights and RIVAL by Osram LED Lights available separately
-
Departure Angle: Optimised design maintains maximum departure angle
-
Number Plate: Integrated number plate mount
-
Compliance: Engineered to Australian standards
-
Fitment: Isuzu D-Max (2017–2019) — All variants
Why Choose Aluminium Over Steel?
Reduced Rear-End Weight
At 45 kg, this bar preserves the D-Max’s payload capacity and towing dynamics compared to heavier steel alternatives.
Superior Corrosion Resistance
Naturally resistant to rust — ideal for coastal construction work, tropical touring conditions and dusty outback environments where steel corrodes quickly.
Engineered Energy Management
Aluminium deforms progressively under impact, assisting in energy dispersion during low-speed reversing impacts.
Optimised for Modern Vehicles
Compact, lightweight design maintains maximum departure angle and supports correct vehicle dynamics under towing loads.
What's Included
- ✓ 1x RIVAL Aluminium Rear Bar
- ✓ Complete mounting hardware & bolts
- ✓ Installation instructions
Not Included: Spotlights, tow hitch, shackles (sold separately). RIVAL Spotlights and RIVAL by Osram LED Lights can be purchased separately.
Installation
Difficulty Level: Moderate — Professional installation recommended
Requirements: Standard hand tools, torque wrench
Direct Bolt-On Design — Full OE rear bumper replacement. No drilling or permanent chassis modifications required.
Professional installation available through RIVAL’s national dealer network.
ADR Compliance & Safety
- ✓ Sensor Compatible — Works with factory rear parking sensors
- ✓ Crash Tested — Engineered to maintain vehicle safety systems
Perfect For
- Touring & Remote Australian Travel
- Coastal & Corrosion-Prone Environments
- Tradies & Fleet Operators
- Towing Caravans, Boats & Trailers
- Owners Who Prefer Their Own Lighting Setup
Compatibility
Fits: Isuzu D-Max (2017–2019) — All variants including:
SX, EX, LS-M, LS-U, LS-T, X-Runner
Engines: 3.0L Turbo-Diesel (4JJ1-TC)
Towing Compatibility
Rated to 3,500 kg towing capacity. Compatible with factory and aftermarket tow hitches and tongue assemblies. Ideal for caravans, boat trailers, camper trailers and box trailers.
Why RIVAL 4x4?
Australian-Based Operations & Support
Local team providing dedicated technical assistance and warranty support.
Globally Engineered. Locally Proven.
Developed using advanced manufacturing processes and tested in Australian touring and off-road conditions.
High-Strength Aluminium Construction
Exceptional strength-to-weight performance and corrosion resistance.
Fast Australia-Wide Dispatch
Reliable delivery nationwide from local warehouses.
National Dealer & Installation Network
Trusted dealers and professional installers across major cities and regional Australia.
Same tough rear bar, your choice of lights — D-Max protection done your way. Order now!
